Arcam SA20 Integrated Amplifier
0
Shipping is calculated at checkout
Description
The Arcam SA20 is a high-performance stereo integrated amplifier that delivers exceptional sound quality by combining the efficiency of Class G amplification with a premium built-in DAC. Designed for audiophiles and music enthusiasts, it offers 90 watts per channel into 8 ohms with ultra-low distortion and an extended frequency response, ensuring precise, dynamic, and immersive audio reproduction.
At the heart of the SA20 is the ESS ES9018K2M Sabre32 Ultra DAC, supporting high-resolution audio formats up to 32-bit/384kHz PCM and DSD256, making it ideal for streaming services, digital libraries, and local playback. It features a versatile range of inputs, including USB-B, optical, coaxial, and analog, along with a built-in MM phono stage—perfect for integrating a turntable into your setup without needing an external preamp.
Brand: Arcam
SKU: N/A
Specifications
Feature | Details |
|---|---|
Model | Arcam SA20 Integrated Amplifier |
Amplifier Type | Class G stereo integrated amplifier |
Output Power | 90W per channel (8Ω), 140W per channel (4Ω) |
Frequency Response | 10 Hz – 60,000 Hz (+0/-3 dB) |
Total Harmonic Distortion (THD) | < 0.0025% (at 1 kHz, 1W into 8Ω) |
Signal-to-Noise Ratio | > 108 dB (A-weighted, input shorted) |
DAC (Digital-to-Analog Converter) | ESS ES9018K2M Sabre32 Ultra DAC |
DAC Resolution | Up to 32-bit/384kHz (PCM), DSD256 (DoP) |
Digital Inputs | 1 × USB-B (asynchronous, Class 2.0), 1 × Optical (Toslink), 1 × Coaxial (RCA) |
Analog Inputs | 3 × RCA line-level, 1 × MM phono input (for turntable) |
Headphone Output | 6.35 mm (1/4") front-panel jack with dedicated headphone amplifier |
Speaker Outputs | Dual sets (A/B), bi-wire capable |
Preamp Output | Yes – for connection to external power amplifier |
Remote Control | Full-function IR remote included |
Display | High-visibility OLED display (shows source, volume, sample rate, format) |
Audio Features | Advanced upsampling, adaptive digital filtering, low-jitter clocking, high-quality linear power supply |
Construction | Rigid steel chassis with aluminum front panel, anti-vibration feet |
Dimensions (W × H × D) | 430 × 96 × 365 mm (16.9 × 3.8 × 14.4 in) |
Weight | 10.5 kg (23.1 lbs) |
Color | Black |
Warranty | 5-year manufacturer warranty |
In the Box
Arcam SA20 Integrated Amplifier
Full-Function IR Remote Control
AAA Batteries (for remote)
USB Cable (for PC/Mac connection)
Detachable AC Power Cord
Quick Start Guide
User Manual
Warranty Card
Specifications
Feature | Details |
|---|---|
Model | Arcam SA20 Integrated Amplifier |
Amplifier Type | Class G stereo integrated amplifier |
Output Power | 90W per channel (8Ω), 140W per channel (4Ω) |
Frequency Response | 10 Hz – 60,000 Hz (+0/-3 dB) |
Total Harmonic Distortion (THD) | < 0.0025% (at 1 kHz, 1W into 8Ω) |
Signal-to-Noise Ratio | > 108 dB (A-weighted, input shorted) |
DAC (Digital-to-Analog Converter) | ESS ES9018K2M Sabre32 Ultra DAC |
DAC Resolution | Up to 32-bit/384kHz (PCM), DSD256 (DoP) |
Digital Inputs | 1 × USB-B (asynchronous, Class 2.0), 1 × Optical (Toslink), 1 × Coaxial (RCA) |
Analog Inputs | 3 × RCA line-level, 1 × MM phono input (for turntable) |
Headphone Output | 6.35 mm (1/4") front-panel jack with dedicated headphone amplifier |
Speaker Outputs | Dual sets (A/B), bi-wire capable |
Preamp Output | Yes – for connection to external power amplifier |
Remote Control | Full-function IR remote included |
Display | High-visibility OLED display (shows source, volume, sample rate, format) |
Audio Features | Advanced upsampling, adaptive digital filtering, low-jitter clocking, high-quality linear power supply |
Construction | Rigid steel chassis with aluminum front panel, anti-vibration feet |
Dimensions (W × H × D) | 430 × 96 × 365 mm (16.9 × 3.8 × 14.4 in) |
Weight | 10.5 kg (23.1 lbs) |
Color | Black |
Warranty | 5-year manufacturer warranty |
In the Box
Arcam SA20 Integrated Amplifier
Full-Function IR Remote Control
AAA Batteries (for remote)
USB Cable (for PC/Mac connection)
Detachable AC Power Cord
Quick Start Guide
User Manual
Warranty Card
