Arcam SA30 Stereo integrated amplifier with built-in DAC
0
Shipping is calculated at checkout
Description
The Arcam SA30 is a high-performance stereo integrated amplifier that combines powerful Class G amplification with a premium-grade built-in DAC for exceptional audio fidelity. Designed for audiophiles and music lovers alike, it delivers 150 watts per channel into 8 ohms with ultra-low distortion and an expansive frequency response. The integrated ESS Sabre32 Ultra DAC supports high-resolution audio up to 32-bit/384kHz and DSD256, making it ideal for streaming, digital files, and vinyl playback (via MM phono input). With multiple digital and analog inputs, including USB, optical, coaxial, and a dedicated turntable input, the SA30 serves as a versatile hub for any modern audio system. Its elegant OLED display, bi-amp capability, and premium build quality make it a standout choice for those seeking both performance and elegance in a single component.
Brand: Arcam
SKU: N/A
Specifications
Feature | Details |
|---|---|
Model | Arcam SA30 Stereo Integrated Amplifier with Built-in DAC |
Amplifier Type | Class G stereo integrated amplifier |
Output Power | 150W per channel (8Ω), 250W per channel (4Ω) |
Frequency Response | 10 Hz – 60,000 Hz (+0/-3 dB) |
Total Harmonic Distortion (THD) | < 0.0025% (at 1 kHz, 1W into 8Ω) |
Signal-to-Noise Ratio | > 108 dB (A-weighted, input shorted) |
DAC (Digital-to-Analog Converter) | ESS ES9018K2M Sabre32 Ultra DAC |
DAC Resolution | Up to 32-bit/384kHz (PCM), DSD256 (DoP) |
Digital Inputs | 1 × USB-B (asynchronous, Class 2.0), 1 × Optical (Toslink), 1 × Coaxial (RCA) |
Analog Inputs | 3 × RCA line-level, 1 × MM phono input (for turntable) |
Headphone Output | 6.35 mm (1/4") front-panel jack with dedicated headphone amplifier |
Speaker Outputs | Dual sets (A/B), bi-wire capable |
Preamp Output | Yes – for connecting to external power amplifier |
Remote Control | Full-function IR remote included |
Display | High-visibility OLED display (shows source, volume, sample rate, format) |
Audio Features | Advanced upsampling, adaptive digital filtering, low-jitter clocking, high-quality linear power supply |
Construction | Steel chassis with aluminum front panel, anti-vibration feet |
Dimensions (W × H × D) | 430 × 96 × 365 mm (16.9 × 3.8 × 14.4 in) |
Weight | 11.5 kg (25.4 lbs) |
Color | Black |
Warranty | 5-year manufacturer warranty |
In the Box
Arcam SA30 Stereo Integrated Amplifier
Full-Function IR Remote Control
AAA Batteries (for remote)
USB Cable (for PC/Mac connection)
Detachable AC Power Cord
Quick Start Guide
User Manual
Warranty Card
Specifications
Feature | Details |
|---|---|
Model | Arcam SA30 Stereo Integrated Amplifier with Built-in DAC |
Amplifier Type | Class G stereo integrated amplifier |
Output Power | 150W per channel (8Ω), 250W per channel (4Ω) |
Frequency Response | 10 Hz – 60,000 Hz (+0/-3 dB) |
Total Harmonic Distortion (THD) | < 0.0025% (at 1 kHz, 1W into 8Ω) |
Signal-to-Noise Ratio | > 108 dB (A-weighted, input shorted) |
DAC (Digital-to-Analog Converter) | ESS ES9018K2M Sabre32 Ultra DAC |
DAC Resolution | Up to 32-bit/384kHz (PCM), DSD256 (DoP) |
Digital Inputs | 1 × USB-B (asynchronous, Class 2.0), 1 × Optical (Toslink), 1 × Coaxial (RCA) |
Analog Inputs | 3 × RCA line-level, 1 × MM phono input (for turntable) |
Headphone Output | 6.35 mm (1/4") front-panel jack with dedicated headphone amplifier |
Speaker Outputs | Dual sets (A/B), bi-wire capable |
Preamp Output | Yes – for connecting to external power amplifier |
Remote Control | Full-function IR remote included |
Display | High-visibility OLED display (shows source, volume, sample rate, format) |
Audio Features | Advanced upsampling, adaptive digital filtering, low-jitter clocking, high-quality linear power supply |
Construction | Steel chassis with aluminum front panel, anti-vibration feet |
Dimensions (W × H × D) | 430 × 96 × 365 mm (16.9 × 3.8 × 14.4 in) |
Weight | 11.5 kg (25.4 lbs) |
Color | Black |
Warranty | 5-year manufacturer warranty |
In the Box
Arcam SA30 Stereo Integrated Amplifier
Full-Function IR Remote Control
AAA Batteries (for remote)
USB Cable (for PC/Mac connection)
Detachable AC Power Cord
Quick Start Guide
User Manual
Warranty Card
