KEF Ci160 QR 2-way Uni-Q in-ceiling Round Speaker White
0
Shipping is calculated at checkout
Description
KEF Ci160QR
The KEF Ci160QR is a high-performance in-ceiling speaker designed to deliver exceptional sound quality with a discreet and modern aesthetic. Featuring KEF's patented Uni-Q driver array, it positions the tweeter at the acoustic center of the bass/midrange cone, allowing both to act as a single point source that disperses sound widely and evenly throughout the room. This design ensures a consistent and immersive listening experience from any location. The speaker boasts a 160mm (6.5in) Uni-Q driver array with a 19mm (0.75in) aluminum dome tweeter and 'tangerine' waveguide, enhancing high-frequency dispersion. Its ultra-thin bezel (UTB™) and magnetic grille provide a sleek, flush-mount appearance that integrates seamlessly into various ceiling designs. Additionally, the Ci160QR is IP64 certified, making it suitable for both indoor and partially exposed outdoor environments.
Brand: KEF
SKU: N/A
Specifications
Feature | Details |
|---|---|
Model | KEF Ci160 QR |
Product Type | In-Ceiling 2-Way Architectural Speaker |
Driver Unit | 160 mm (6.5 in.) Uni-Q driver array with 19 mm aluminum dome tweeter |
Frequency Response | 45 Hz – 20 kHz (±6 dB, open-backed) |
Impedance | 8 Ω |
Sensitivity | 88 dB (2.83V/1m) |
Recommended Amplifier Power | 10 – 100 W |
Crossover Frequency | 2.5 kHz |
Design Features | Quick Release (QR) magnetic grille for fast installation, Uni-Q technology for wide dispersion, paintable finish, thin bezel |
Mounting Depth | 90 mm (3.54 in.) |
Cut-Out Dimensions | Ø 184 mm (7.24 in.) |
External Dimensions | Ø 219 mm (8.62 in.) |
Weight | 1.5 kg (3.31 lbs) |
Grille Finish | White (paintable) |
Warranty | 5 years (manufacturer) |
In the Box
KEF Ci160 QR Speaker
Magnetic Paintable Grille
Mounting Template
User Manual
Warranty Information
