KEF Ci3160RLb
0
Shipping is calculated at checkout
Description
The KEF Ci3160RLb is a professional-grade in-wall subwoofer certified to THX Ultra/Select standards, delivering deep, room-shaking bass while seamlessly fitting flush into walls. Equipped with three 160 mm low-frequency drivers mounted on an aluminum baffle, it achieves powerful and precise output from 20 Hz up to 140 Hz. Designed for custom installations and premium home theaters, it must be paired with KEF’s KASA500 amplifier (supports up to two subwoofers). Despite its robust performance, the Ci3160RLb maintains a low profile at just under 100 mm depth, making it ideal for those seeking high-impact audio without bulky floor units.
Brand: KEF
SKU: N/A
Specifications
Feature | Details |
|---|---|
Model | KEF Ci3160RLb |
Product Type | In-Wall Subwoofer (Custom Installation) |
Driver Units | 3 × 160 mm (6.5 in.) LF drivers |
Frequency Response | 30 Hz – 140 Hz (±6 dB, depending on baffle wall conditions) |
Impedance | 8 Ω |
Sensitivity | 87 dB (2.83V/1m) |
Recommended Amplifier Power | 50 – 300 W |
Design Features | Designed for KEF THX-certified Extreme Home Theatre, sealed aluminum baffle for rigidity, slim profile |
Mounting Depth | 95 mm (3.74 in.) |
Cut-Out Dimensions | 1158 mm × 164 mm (45.59 × 6.46 in.) |
External Dimensions | 1186 mm × 192 mm (46.69 × 7.56 in.) |
Weight | 16.5 kg (36.4 lbs) |
Grille Finish | White, paintable magnetic grille |
Certification | THX Ultra Certified |
Warranty | 5 years (manufacturer) |
In the Box
KEF Ci3160RLb In-Wall Subwoofer
Magnetic Paintable Grille
Mounting Template
Installation Guide
Warranty Information
